Eutectic Hard Top Freezer
Silent Features:
- High density 31-38 Kg/m³ Polyurethane foam and calculated critical insulation thickness to avoid heatransfer from freezer.
- Eutectic solutions jackets are used in inner tank This type of freezer can keep Ice-Cream from melting for 15 hours without electricity.
- Compact design with maximum coverage capacity.
- H F C 1 3 4a / 4 0 4 ecofriendly refrigerants.
- Avoid skin condenser due to draw back instead of that use auxiliary condenser. The condenser are designed by calculating enthalpy of system considering maximum ambient temperature.
- Branded Compressor are used but do not apply for over capacity systems.Designed is based on compressor capacity not on system.
Available in models
| Model |
Vol.Lit | Dimension W×L×H inc | Temperature | No.of Doors | Consumption Units/24Hr |
| Ht 200 |
200 | 32×24×37 | -32°C ± 3°C | 1 | 2.0 |
| Ht 300 |
300 | 42×24×37 | -32°C ± 3°C | 2 | 3.0 |
| Ht 400 |
400 | 54×24×37 | -32°C ± 3°C | 2 | 4.0 |
| Ht 500 |
500 | 68×24×37 | -32°C ± 3°C | 3 | 5.0 |
